Quantum power wheelchairs are well known for their advanced seating technology, designed to support comfort, positioning, and independence. With the introduction of the TRU-Balance 4 (TB4) seating system, users now have more choice than ever, but it’s important to note that TRU-Balance 3 (TB3) is still very much part of the range.
So, what’s the difference between TB3 and TB4, and how do you decide which one is the better fit? Let’s take a closer look...
TRU-Balance 3: A Proven, Versatile Seating System
|
TRU-Balance 3 is the seating system many Quantum users are already familiar with. It offers a strong combination of positioning and functional support, including:
TB3 remains an excellent choice for users who need reliable pressure management, repositioning, and day-to-day comfort without more advanced positioning features. |
What’s New with TRU-Balance 4?
|
TRU-Balance 4 builds on the strengths of TB3, adding several advanced features aimed at improving function, transfers, and ease of use. TB4 is currently available on the Stretto, Edge 3, and 4Front 2 power wheelchair bases. |
1. Dual-Actuator Articulating Foot Platform
Unlike the single-actuator system on TB3, TB4 uses dual actuators to allow the footplates to move independently of leg elevation.
This means:
- Footplates can lower all the way to the floor
- Users don’t need to flip footplates out of the way manually
- Caregivers can better support transfers
This feature is especially helpful for:
- Sit-to-stand transfers
- Squat pivot transfers
- Users who want more control over lower-limb positioning
It also allows fine adjustment of leg extension and articulation, improving comfort and positioning throughout the day.
2. Memory Seating Positions
TRU-Balance 4 introduces programmable memory seating, making it easy to move into frequently used positions at the touch of a button.
Users can store:
- Up to eight unique seating positions
- Two positions within each of the four profiles
Common examples include:
- Transfer positions
- Relaxation or TV viewing
- Vehicle access
- Cooking or functional reach
- Weight-shifting positions
Memory seating can be set up in two ways:
-
Synchronised - all actuators move together smoothly
- Sequential - one function moves at a time, useful for specific weight-shift techniques
This feature improves efficiency, consistency, and independence.
3. Power Anterior Tilt: A Major Advancement
One of the biggest additions with TB4 is power anterior tilt.
While power seat elevation helps with vertical access, anterior tilt offers something different:
- Improved forward reach
- Better balance during reaching tasks
- Reduced effort from the trunk and upper body
By gently tilting the user forward in a controlled way, anterior tilt helps bring the person closer to what they’re reaching for, rather than requiring them to lean or overextend.
Supporting Transfers with Anterior Tilt
For users who:
Anterior tilt helps position the pelvis and legs more favourably, reducing the physical effort required to stand or transfer safely. |
 |
Choosing Between TB3 and TB4
There’s no “one-size-fits-all” answer.
-
TRU-Balance 3 remains a highly capable seating system for many users
- TRU-Balance 4 adds advanced positioning, transfer assistance, and convenience features
The best choice depends on the individual’s mobility, strength, balance, daily activities, and goals. Trialling both options with a qualified provider is the best way to determine which system offers the greatest independence and comfort.
Written by Chris Summers
Chris is a Complex Product Category Manager at Allied Medical and works closely with our Technical Product Specialists, Customer Care Team and Technicians to ensure our complex equipment range meets the needs of customers, assessors and funders.
